Sigma 1062 Dry Asbestos with PTFE impregnated Gland Packing


ITEM :- Sigma 1062

PRODUCT NAME :- Sigma 1062 Dry Asbestos with PTFE impregnated Gland Packing

BRAND :- SIGMA PLACE OF ORIGIN : INDIA

CERTIFICATION :- API, ISO 9001




APPLICATIONS / USES :-Asbestos braided packing impregnated with PTFE is braided from high quality asbestos yarns impregnated with PTFE dispersion. High performance gland packing made of High grade Asbestos fibre yarn duplex braid interlock construction to increase dimension stability of Gland packing, then superbly impregnated with PTFE (Poly Tetra Fluro Ethylene) Suspension with latest technology.

Product Description
A good gland packing ring to seal against Acids, Alkali solutions, Agressive organic / inorganic Chemical Rotary and reciprocating plant pumps & valves. oils, corrosive chemical & gases, petroleum byproducts, oxygen services, Dyestuffs, synthetic resins, paints, pulp & paper sector chemicals. Equipment glands where no contamination is allowed. Not recommended to use on molten metals, concentrated acids and gaseous fluorine.

Service Limits, Application Parameter


  Specification
Pressure bar
to 300 psi (20 bar) rotary/ centrifugal;  to 2000 psi (138 bar) valves
Density g/cm3
1.4
Temperature °C
-4500F (-2700C) to +5000F(+2600C)
Shaft Speed
  to 4500 rpm
PH range
0-14

Available on demand: Square Section 6 mm sq upto 38 mm sq.sq.


Prime Features

  • Clean non contamination and graphite free.
  • Long maintenance free service life.
  • Minimal shaft wear and leakage
  • Pliable, wear-resistant and dimensionally stable


  • Resists most chemicals & caustic media
  • Rugged and non-toxic
  • High density, dimensionally stable - very little water absorption
  • Ideal for valve and slower shaft speed applications

Our motto is to provide best international quality products at very competative price.
